Parent Layer: Storm

Name: Abandoned Stormwater Pipes

Display Field: DBID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;font-size:12pt"><P><SPAN>Displays the approximate location of abandoned stormwater pipes that are disconnected from the city’s system. For general information on city utilities contact the City of Manhattan, KS Public Works Department at (785) 587-2415. They can help put you in contact with the correct utility administrator.</SPAN></P></DIV>

Service Item Id: 4f068613ab3a4ddfa7a0fea23b26db5b

Copyright Text: MHK GIS and Public Works

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1685432.572359383
YMin: 294246.4668914825
XMax: 1731103.3173038065
YMax: 327500.9535319805
Spatial Reference: 102677  (3419)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [115, 0, 76, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: SHAPE )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• DBID ( type: esriFieldTypeInteger, alias: Database ID , Range: [0, 49999] )
• ASSETID ( type: esriFieldTypeString, alias: Asset ID, length: 23 )
• PIPETYPE ( type: esriFieldTypeString, alias: Pipe Type, length: 15 , Coded Values: [Unknown: Unknown] , [Gravity: Gravity] , [Force: Force] , ...2 more... )
• PIPEDIAM ( type: esriFieldTypeSmallInteger, alias: Pipe Diameter of Height )
• PIPEWIDTH ( type: esriFieldTypeSmallInteger, alias: Pipe Width )
• PIPESHP ( type: esriFieldTypeString, alias: Pipe Shape, length: 25 , Coded Values: [Unknown: Unknown] , [Round Pipe: Round Pipe] , [Elliptical Pipe: Elliptical Pipe] , ...5 more... )
• PIPEMAT ( type: esriFieldTypeString, alias: Pipe Material, length: 30 , Coded Values: [Unknown: Unknown] , [ABS Plastic: ABS Plastic] , [Asbestos Cement: Asbestos Cement] , ...31 more... )
• LEVEE ( type: esriFieldTypeString, alias: In Levee, length: 7 , Coded Values: [No: No] , [Yes: Yes] , [Unknown: Unknown] , ...1 more... )
• PIPELEN ( type: esriFieldTypeDouble, alias: Pipe Length )
• PIPESLP ( type: esriFieldTypeDouble, alias: Pipe Slope )
• FROMELEV ( type: esriFieldTypeDouble, alias: Upstream Invert )
• TOELEV ( type: esriFieldTypeDouble, alias: Downstream Invert )
• FROMNODE ( type: esriFieldTypeString, alias: Upstream Node ID, length: 10 )
• TONODE ( type: esriFieldTypeString, alias: Downstream Node ID, length: 10 )
• INSTALLTYPE ( type: esriFieldTypeString, alias: Install Type, length: 20 , Coded Values: [Unknown: Unknown] , [Aerial: Aerial] , [Bore: Bore] , ...3 more... )
• PRJNUM ( type: esriFieldTypeString, alias: Project Number, length: 10 )
• APRJNUM ( type: esriFieldTypeString, alias: Alternate Project Number, length: 25 )
• YEARBUILT ( type: esriFieldTypeSmallInteger, alias: Year Built )
• STATUS ( type: esriFieldTypeString, alias: Status, length: 20 , Coded Values: [Unknown: Unknown] , [Operational: Operational] , [Built: Built] , ...6 more... )
• OWNEDBY ( type: esriFieldTypeString, alias: Owned By, length: 25 , Coded Values: [Unknown: Unknown] , [City of Manhattan: City of Manhattan] , [Riley County: Riley County] , ...11 more... )
• MAINTBY ( type: esriFieldTypeString, alias: Maintained By, length: 25 , Coded Values: [Unknown: Unknown] , [MHK Sewer Maintenance: MHK Sewer Maintenance] , [MHK Water Distribution: MHK Water Distribution] , ...19 more... )
• OLDID ( type: esriFieldTypeString, alias: Old ID, length: 10 )
• CREATOR ( type: esriFieldTypeString, alias: Created By, length: 50 )
• CREATED ( type: esriFieldTypeDate, alias: Created On, length: 8 )
• LASTEDITOR ( type: esriFieldTypeString, alias: Last Edited By, length: 50 )
• LASTEDITED ( type: esriFieldTypeDate, alias: Last Edited On, length: 8 )
• LucityAutoID ( type: esriFieldTypeInteger, alias: Link to Lucity )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
